Union Special
2200FAC



Portable Sewing Machine
1 Thread, Special: 42v


union_special_spare_parts
union_special_manuals
  • About Machine

    Union Special 2200FAC

    Portable Single Thread Chain-Stitch Sewing Machine

    For Dyeing and Finishing Section.

    Portable single thread chain stitch sewing machine with direct drive by fan-cooled electric motor

    Due to the 42 V motor and the rust resisting sewing parts, the machine is particularly suitable for sewing under wet conditions.

    Combined upper and lower feed for greater power grips both sides of the bag, even on difficult materials.

    Motor housing and handle made of fibre-glass reinforced break-resistant polyamide.

    Sealed, dustproof and permanently lubricated motor ball bearings.

    Power cable 5 m long.

    Union Special on YouTube

  • Specification

    Machine Specifications

    Series

    2200

    Threads

    1 Thread

    Handling

    Portable, Suspended

    Power

    42v

    Start/Stop

    Hand Switch

    Protection

    Class III

    Weight

    5kg

    Materials

    Knitwear, Woven Fabric

    Closure Type

    Plain Closure

    Stitch Range

    3 – 9mm

    Foot Lift

    9mm

    Thread Chain & Tape Cutter

    Continuously Driven Nibbler Knife

    Feed Type

    Top and Bottom Feed

    Lubrication

    Manual
